Vite Integration

Litestar Vite provides seamless integration with Vite, a modern frontend build tool.

Installation

Install the package:

pip install litestar-vite

Note

Nodeenv integration is opt-in. To let litestar-vite provision Node inside your virtualenv, install with litestar-vite[nodeenv] and enable nodeenv detection (for example runtime.detect_nodeenv=True or make install NODEENV=1). Otherwise, ensure Node/npm is available on your system.

Setup Options

There are two ways to set up Vite with Litestar:

1. Using the CLI (Recommended)

The CLI provides a streamlined setup process:

# Initialize a new Vite project (React default)
litestar assets init

# Inertia templates keep Laravel-style paths under resources/
litestar assets init --template vue-inertia

# Non-Inertia templates default to src/; place everything under web/
litestar assets init --template react --frontend-dir web

This command will:

• Create a new Vite project structure

• Install necessary dependencies

• Set up configuration files

• Create example templates

The generated project structure will look like this:

my_project/
├── public/           # Compiled assets
├── src/              # Frontend source (default for non-Inertia)
├── resources/        # Frontend source (Inertia templates only)
├── package.json      # Node.js dependencies
├── vite.config.js    # Vite configuration
└── pyproject.toml    # Python dependencies

2. Manual Setup

If you prefer more control, you can set up Vite manually:

1. Initialize the frontend project:

npm init -y
npm install vite
npm install -D litestar-vite-plugin

2. Create vite.config.js:

import { defineConfig } from 'vite'
import litestar from 'litestar-vite-plugin'

export default defineConfig({
    plugins: [
        litestar({
            input: ['src/main.ts'],
        })
    ]
})
// For Inertia templates, use resources/main.ts instead

Configuration

The integration is configured in two places: the Python backend via the VitePlugin and the frontend via the litestar-vite-plugin in your vite.config.ts.

Python Configuration (ViteConfig)

You configure the Litestar backend using the ViteConfig object passed to the VitePlugin. The configuration is now organized into nested objects.

from litestar import Litestar
from litestar_vite import ViteConfig, VitePlugin
from litestar_vite.config import PathConfig, RuntimeConfig

app = Litestar(
    plugins=[
        VitePlugin(
            config=ViteConfig(
                paths=PathConfig(
                    bundle_dir="public",
                    resource_dir="src",  # use "resources" for Inertia templates
                ),
                runtime=RuntimeConfig(
                    port=5173,
                    hot_reload=True,
                ),
                mode="spa", # or "template", "htmx"
            )
        )
    ]
)

Root `ViteConfig` Parameters:

Parameter	Type	Description
mode	str	Operation mode: “spa”, “template”, or “htmx”. Defaults to “spa”.
paths	PathConfig	File system paths configuration.
runtime	RuntimeConfig	Runtime execution settings.
types	TypeGenConfig | bool	Type generation settings.
inertia	InertiaConfig | bool	Inertia.js settings.
dev_mode	bool	Shortcut to enable development mode.

`PathConfig` Parameters:

Parameter	Type	Description
bundle_dir	Path | str	Location of compiled assets. Defaults to “public”.
resource_dir	Path | str	Directory for source files. Defaults to “src” (use “resources” for Inertia templates).
public_dir	Path | str	The public directory Vite serves assets from. Defaults to “public”.
manifest_name	str	Name of the Vite manifest file. Defaults to “manifest.json”.
hot_file	str	Name of the hot file. Defaults to “hot”.
asset_url	str	Base URL for static assets. Defaults to “/static/”.

`RuntimeConfig` Parameters:

Parameter	Type	Description
dev_mode	bool	Enable development mode.
hot_reload	bool	Enable Hot Module Replacement.
host	str	Host for Vite dev server. Defaults to “localhost”.
port	int	Port for Vite dev server. Defaults to 5173.
executor	str	JS executor (“node”, “bun”, “deno”). Defaults to “node”.

Vite Plugin Configuration (litestar-vite-plugin)

You configure the Vite frontend build process in your vite.config.ts (or .js).

import { defineConfig } from 'vite'
import litestar from 'litestar-vite-plugin'

export default defineConfig({
    plugins: [
        litestar({
            // Add your configuration options here
            input: ['src/main.ts'], // use resources/main.ts for Inertia templates
        })
    ]
})

Available Plugin Parameters:

Parameter	Type	Description
input	string | string[]	Required. The path or paths of the entry points to compile.
assetUrl	string	The base path for asset URLs. Defaults to ‘/static/’.
bundleDirectory	string	The directory where compiled assets are written. Defaults to ‘public/dist’.
resourceDirectory	string	The directory for source assets. Defaults to ‘src’ (use ‘resources’ for Inertia templates).
hotFile	string	The path to the “hot” file. Defaults to ${bundleDirectory}/hot.
types	object | boolean	Type generation configuration.

Template Integration

Use the vite() and vite_hmr() callables in your Jinja2 templates to include the assets (in Template Mode).

<!DOCTYPE html>
<html>
<head>
    {{ vite('src/css/styles.css') }}
</head>
<body>
    <div id="app"></div>
    {{ vite_hmr() }}
    {{ vite('src/js/main.js') }}
</body>
</html>

Angular options

Litestar Vite supports Angular in two ways:

• Angular (Vite / Analog) – litestar assets init –template angular

  • Uses @analogjs/vite-plugin-angular together with litestar-vite-plugin.

  • Source dir: src/; hotfile at public/hot; single-port proxy/HMR enabled by default.

  • Typed routes/OpenAPI generation on by default (writes to src/generated).

• Angular CLI (non-Vite) – litestar assets init –template angular-cli

  • Runs via Angular CLI ng serve with proxy.conf.json targeting Litestar.

  • Source dir: src/; does not use litestar-vite-plugin or the typed-routes pipeline.

  • Use npm start / npm run build and serve dist/browser/ via Litestar static files.

Troubleshooting (Angular)

• HMR not connecting (Analog): ensure /vite-hmr and /@analogjs/ are proxied; stay in single-port mode or expose Vite directly.

• Types not generating (Analog): install @hey-api/openapi-ts or set types.enabled=false in vite.config.ts.

• Angular CLI path: confirm backend runs on port 8000 (or update proxy.conf.json targets).

Framework comparison (scaffolds)

Framework	Source dir	Dev server / proxy	Type generation
React/Vue/Svelte	src/	Vite + litestar-vite proxy	Enabled by default
Inertia variants	resources/	Vite + litestar-vite proxy	Enabled by default
Angular (Analog)	src/	Vite (Analog) + proxy	Enabled by default
Angular CLI	src/	Angular CLI + proxy.conf.json	Disabled (CLI handles dev)
HTMX	src/	Vite + litestar-vite proxy	Disabled (JS optional)

Advanced Asset Handling

For assets that are not entry points but still need to be referenced (e.g., images processed by Vite), you can use the vite_static template callable:

<img src="{{ vite_static('src/images/logo.png') }}" alt="Logo" />

This resolves the correct URL whether you are in development mode (served by Vite) or production mode (hashed URL from manifest).

Development Workflow

Development Server

When use_server_lifespan is set to True (default when dev_mode=True), the Litestar CLI will automatically manage the Vite development server.

litestar run

Proxy vs direct modes:

• Proxy (default): Litestar proxies Vite HTTP + WS/HMR through the ASGI port. Vite binds to loopback with an auto-picked port if VITE_PORT is unset, writes public/hot with its URL, and the JS plugin reads it. Paths like /@vite/client, /@fs/, /node_modules/.vite/, /src/, /__vite_ping are forwarded, including WebSockets.

• Direct: classic two-port setup; Vite is exposed on VITE_HOST:VITE_PORT and Litestar does not proxy it.

Switch with VITE_PROXY_MODE=proxy|direct (or ViteConfig.runtime.proxy_mode).

If you prefer to manage the Vite server manually, set dev_mode=False in config but run vite manually:

Terminal 1: Start Vite Dev Server

npm run dev

Terminal 2: Run Litestar App

litestar run

Production

Building Assets

Build your assets for production using the CLI:

litestar assets build

This command bundles and optimizes all assets, generates a manifest file, and outputs the files to the configured bundle_dir.

For more information about Inertia integration, refer to the Inertia documentation.
