Vite Integration¶

Litestar Vite provides seamless integration with Vite, a modern frontend build tool.

Installation¶

Install the package:

pip install litestar-vite

Note

Nodeenv integration is opt-in. To let litestar-vite provision Node inside your virtualenv, install with litestar-vite[nodeenv] and enable nodeenv detection (for example runtime.detect_nodeenv=True or make install NODEENV=1). Otherwise, ensure Node/npm is available on your system.

Setup Options¶

There are two ways to set up Vite with Litestar:

1. Using the CLI (Recommended)¶

The CLI provides a streamlined setup process:

# Initialize a new Vite project (React default)
litestar assets init

# Available templates:
# SPA: react, react-router, react-tanstack, vue, svelte
# Inertia: react-inertia, vue-inertia, svelte-inertia
# SSR: sveltekit, nuxt, astro
# Other: angular, angular-cli, htmx

# Inertia templates keep Laravel-style paths under resources/
litestar assets init --template vue-inertia

# Non-Inertia templates default to src/; place everything under web/
litestar assets init --template react-router --frontend-dir web

This command will:

Create a new Vite project structure
Install necessary dependencies
Set up configuration files
Create example templates

The generated project structure will look like this:

my_project/
├── public/           # Compiled assets
├── src/              # Frontend source (default for non-Inertia)
├── resources/        # Frontend source (Inertia templates only)
├── package.json      # Node.js dependencies
├── vite.config.js    # Vite configuration
└── pyproject.toml    # Python dependencies

2. Manual Setup¶

If you prefer more control, you can set up Vite manually:

Initialize the frontend project:

npm init -y
npm install vite
npm install -D litestar-vite-plugin

You can also install the frontend dependencies through the Litestar CLI once your Python config is in place:

litestar assets install

Create vite.config.js:

import { defineConfig } from 'vite'
import litestar from 'litestar-vite-plugin'

export default defineConfig({
    plugins: [
        litestar({
            input: ['src/main.ts'],
        })
    ]
})
// For Inertia templates, use resources/main.ts instead

Configuration¶

The integration is configured in two places: the Python backend via the VitePlugin and the frontend via the litestar-vite-plugin in your vite.config.ts.

Python Configuration (ViteConfig)¶

You configure the Litestar backend using the ViteConfig object passed to the VitePlugin. The configuration is now organized into nested objects.

from litestar import Litestar
from litestar_vite import ViteConfig, VitePlugin
from litestar_vite.config import PathConfig, RuntimeConfig

app = Litestar(
    plugins=[
        VitePlugin(
            config=ViteConfig(
                paths=PathConfig(
                    bundle_dir="public",
                    resource_dir="src",  # use "resources" for Inertia templates
                ),
                runtime=RuntimeConfig(
                    port=5173,
                    dev_mode=True,
                ),
                mode="spa",  # or "template", "htmx", "hybrid", "framework", "external"
            )
        )
    ]
)

Root `ViteConfig` Parameters:

Parameter	Type	Description
mode	str \| None	Operation mode: “spa”, “template”, “htmx”, “hybrid”, “framework”, “ssr”, “ssg”, or “external”. Auto-detected if not set.
paths	PathConfig	File system paths configuration.
runtime	RuntimeConfig	Runtime execution settings.
types	TypeGenConfig \| bool \| None	Type generation settings. True enables with defaults, False/None disables.
inertia	InertiaConfig \| bool \| None	Inertia.js settings. True enables with defaults, False/None disables.
spa	SPAConfig \| bool \| None	SPA transformation settings.
dev_mode	bool	Shortcut for runtime.dev_mode. Defaults to False.
base_url	str \| None	Public base URL where the frontend entry point is served (e.g. `https://app.example.com/`). This does not affect asset URLs. Reads from `VITE_BASE_URL`.
deploy	DeployConfig \| bool	Deployment configuration for CDN publishing.

`SPAConfig` Parameters:

Parameter	Type	Description
inject_csrf	bool	Inject CSRF token into HTML as window.__LITESTAR_CSRF__. Defaults to True.
csrf_var_name	str	Global variable name for CSRF token. Defaults to “__LITESTAR_CSRF__”.
app_selector	str	CSS selector for the app root element (used for data attributes). Defaults to “#app”.
cache_transformed_html	bool	Cache transformed HTML in production. Automatically disabled when inject_csrf=True since CSRF tokens are per-request. Defaults to True.

`ExternalDevServer` Parameters:

Parameter	Type	Description
target	str \| None	URL of the external dev server (e.g., “http://localhost:4200” for Angular CLI). If None, reads from hotfile (for SSR frameworks using Vite internally).
command	list[str] \| None	Custom command to start the dev server (e.g., [“ng”, “serve”]). If None, uses executor’s default start command.
build_command	list[str] \| None	Custom command to build for production (e.g., [“ng”, “build”]). If None, uses executor’s default build command.
http2	bool	Enable HTTP/2 for proxy connections. Defaults to False.
enabled	bool	Whether the external proxy is enabled. Defaults to True.

`PathConfig` Parameters:

Parameter	Type	Description
root	Path \| str	Root directory of the project. Defaults to current working directory.
bundle_dir	Path \| str	Location of compiled assets and manifest.json. Defaults to “public”.
resource_dir	Path \| str	TypeScript/JavaScript source directory. Defaults to “src” (use “resources” for Inertia templates).
static_dir	Path \| str	Static public assets directory (served as-is by Vite). Defaults to “public”.
manifest_name	str	Name of the Vite manifest file. Defaults to “manifest.json”.
hot_file	str	Name of the hot file indicating dev server URL. Defaults to “hot”.
asset_url	str	Base URL for static asset references in both dev and production. Can be a path (`/static/`) or an absolute URL (CDN/object storage). Defaults to `/static/` or `ASSET_URL`.
ssr_output_dir	Path \| str \| None	SSR output directory. Defaults to None.

`RuntimeConfig` Parameters:

Parameter	Type	Description
dev_mode	bool	Enable development mode with HMR/watch. Reads from VITE_DEV_MODE env var.
proxy_mode	str \| None	Proxy handling mode: “vite” (default, whitelist - proxies Vite assets only), “direct” (expose Vite port directly, no proxy), “proxy” (blacklist - proxies everything except Litestar routes, used for meta-frameworks), or None (disabled, production mode).
external_dev_server	ExternalDevServer \| str \| None	Configuration for external dev servers (Angular CLI, Next.js, etc.). Can be a string URL (e.g., “http://localhost:4200”) or an ExternalDevServer object with target, command, build_command, http2, and enabled fields. When set, automatically switches proxy_mode to “proxy” if not explicitly configured.
host	str	Host for Vite dev server. Defaults to “127.0.0.1” or VITE_HOST env var.
port	int	Port for Vite dev server. Defaults to 5173 or VITE_PORT env var.
protocol	str	Protocol for dev server: “http” or “https”. Defaults to “http”.
executor	str \| None	JS executor: “node”, “bun”, “deno”, “yarn”, or “pnpm”. Defaults to “node”.
is_react	bool	Enable React Fast Refresh support. Defaults to False.
http2	bool	Enable HTTP/2 for proxy HTTP requests (better connection multiplexing). WebSocket/HMR uses a separate connection. Requires h2 package. Defaults to True.
start_dev_server	bool	Auto-start dev server process managed by Litestar. Set to False if managing the dev server externally. Defaults to True.
spa_handler	bool	Auto-register catch-all SPA route when mode=”spa”. Defaults to True.
set_environment	bool	Write .litestar.json config file on startup. Defaults to True.
set_static_folders	bool	Automatically configure static file serving. Defaults to True.
detect_nodeenv	bool	Detect and use nodeenv in virtualenv. Defaults to False.
health_check	bool	Enable health check for dev server startup. Defaults to False.

Vite Plugin Configuration (litestar-vite-plugin)¶

You configure the Vite frontend build process in your vite.config.ts (or .js).

When running via the Litestar CLI (litestar run or litestar assets serve), Python writes a .litestar.json file that the Vite plugin reads automatically. This means only `input` is required - all other settings are inherited from Python:

import { defineConfig } from 'vite'
import litestar from 'litestar-vite-plugin'

export default defineConfig({
    plugins: [
        litestar({ input: ['src/main.ts'] })
    ]
})

For standalone Vite usage (without Litestar), you can specify paths explicitly:

// Only needed when NOT using Litestar CLI
litestar({
    input: ['src/main.ts'],
    assetUrl: '/static/',
    bundleDir: 'public',
    resourceDir: 'src',
})

Available Plugin Parameters:

Parameter	Type	Description
input	string \| string[]	Required. The path or paths of the entry points to compile.
assetUrl	string	The base path for asset URLs. Defaults to ‘/static/’.
bundleDir	string	The directory where compiled assets and manifest.json are written. Defaults to ‘public’.
resourceDir	string	The directory for source assets. Defaults to ‘resources’.
staticDir	string	Directory for static, unprocessed assets (maps to Vite’s publicDir). Defaults to ‘${resourceDir}/public’.
hotFile	string	The path to the “hot” file. Defaults to ‘${bundleDir}/hot’.
ssr	string \| string[]	The path of the SSR entry point.
ssrOutDir	string	The directory where the SSR bundle should be written. Defaults to ‘${bundleDir}/bootstrap/ssr’.
refresh	boolean \| string \| string[] \| RefreshConfig	Configuration for full page refresh on file changes. Defaults to false.
detectTls	string \| boolean \| null	Utilize TLS certificates. Defaults to null.
autoDetectIndex	boolean	Automatically detect and serve index.html. Defaults to true.
inertiaMode	boolean	Enable Inertia mode (disables index.html auto-detection). Auto-detected from .litestar.json when mode is “inertia”. Defaults to false.
types	boolean \| “auto” \| TypesConfig	Type generation configuration. “auto” or undefined reads from .litestar.json (recommended). true enables with hardcoded defaults. false disables. Object allows fine-grained control with fields: enabled, output, openapiPath, routesPath, pagePropsPath, generateZod, generateSdk, globalRoute, debounce. Defaults to undefined (auto-detect).
executor	string	JavaScript runtime: “node”, “bun”, “deno”, “yarn”, or “pnpm”. Auto-detected from Python config.

Diagnostics (litestar assets doctor)¶

When something feels “off” (HMR not connecting, types not generating, manifest missing), run:

litestar assets doctor

For a full config dump (including .litestar.json and the extracted litestar({ ... }) block), add:

litestar assets doctor --show-config

To attempt safe auto-fixes (writes backups next to the edited files):

litestar assets doctor --fix

Runtime-state checks are opt-in (useful when you expect Vite to already be running):

litestar assets doctor --runtime-checks

What it checks (high level):

Your vite.config.* contains a litestar({ ... }) plugin config
.litestar.json exists/is valid/is in sync with Python (when runtime.set_environment=True)
Python vs explicit Vite plugin overrides (assetUrl, bundleDir, resourceDir, staticDir, hotFile, typegen flags)
Core paths exist (resource_dir, static_dir) and entrypoint input files exist
Dev/production artifacts (manifest in prod; hotfile/Vite reachability only with --runtime-checks)
Environment variables that override runtime (VITE_PORT, VITE_HOST, VITE_PROXY_MODE, VITE_BASE_URL)

Note

When runtime.set_environment=True (the default), Litestar writes .litestar.json on startup. If Doctor reports a stale/mismatched bridge file, simply restarting your app (litestar run) will overwrite it; deleting the file is not required.

Template Integration¶

Use the vite() and vite_hmr() callables in your Jinja2 templates to include the assets (in Template Mode).

<!DOCTYPE html>
<html>
<head>
    {{ vite('src/css/styles.css') }}
</head>
<body>
    <div id="app"></div>
    {{ vite_hmr() }}
    {{ vite('src/js/main.js') }}
</body>
</html>

Angular options¶

Litestar Vite supports Angular in two ways:

Angular (Vite / Analog) – litestar assets init –template angular
- Uses @analogjs/vite-plugin-angular together with litestar-vite-plugin.
- Source dir: src/; hotfile at public/hot; single-port proxy/HMR enabled by default.
- Typed routes/OpenAPI generation on by default (writes to src/generated).
Angular CLI (non-Vite) – litestar assets init –template angular-cli
- Runs via Angular CLI ng serve with proxy.conf.json targeting Litestar.
- Source dir: src/; does not use litestar-vite-plugin or the typed-routes pipeline.
- Use the standard Angular CLI commands (npm start / ng build) and serve dist/browser/ via Litestar static files.

Troubleshooting (Angular)¶

HMR not connecting (Analog): ensure /vite-hmr and /@analogjs/ are proxied; stay in single-port mode or expose Vite directly.
Types not generating (Analog): install @hey-api/openapi-ts or set types.enabled=false in vite.config.ts.
Angular CLI path: confirm backend runs on port 8000 (or update proxy.conf.json targets).

Framework comparison (scaffolds)¶

Framework	Source dir	Dev server / proxy	Type generation
React/Vue/Svelte	src/	Vite + litestar-vite proxy	Enabled by default
Inertia variants	resources/	Vite + litestar-vite proxy	Enabled by default
Angular (Analog)	src/	Vite (Analog) + proxy	Enabled by default
Angular CLI	src/	Angular CLI + proxy.conf.json	Disabled (CLI handles dev)
HTMX	src/	Vite + litestar-vite proxy	Disabled (JS optional)

Advanced Asset Handling¶

For assets that are not entry points but still need to be referenced (e.g., images processed by Vite), you can use the vite_static template callable:

<img src="{{ vite_static('src/images/logo.png') }}" alt="Logo" />

This resolves the correct URL whether you are in development mode (served by Vite) or production mode (hashed URL from manifest).

Development Workflow¶

Development Server¶

When use_server_lifespan is set to True (default when dev_mode=True), the Litestar CLI will automatically manage the Vite development server.

litestar run

Proxy vs direct modes:

Proxy (default): Litestar proxies Vite HTTP + WS/HMR through the ASGI port. Vite binds to loopback with an auto-picked port if VITE_PORT is unset, writes public/hot with its URL, and the JS plugin reads it. Paths like /@vite/client, /@fs/, /node_modules/.vite/, /src/, /__vite_ping are forwarded, including WebSockets.
Direct: classic two-port setup; Vite is exposed on VITE_HOST:VITE_PORT and Litestar does not proxy it.

Switch with VITE_PROXY_MODE=proxy|direct (or ViteConfig.runtime.proxy_mode).

If you prefer to manage the Vite server manually, keep dev_mode=True but start Vite yourself (useful for two-port setups):

Terminal 1: Start Vite Dev Server via the Litestar CLI¶

litestar assets serve

Terminal 2: Run Litestar App¶

litestar run

Production¶

Building Assets¶

Build your assets for production using the CLI:

litestar assets build

This command bundles and optimizes all assets, generates a manifest file, and outputs the files to the configured bundle_dir.

Deploying Assets (litestar assets deploy)¶

Deployment has two distinct concepts:

Where files are synced to (fsspec target): DeployConfig.storage_backend (e.g. s3://bucket/assets)
What URLs the browser should use (public URL): DeployConfig.asset_url (e.g. https://cdn.example.com/assets/)

Do not set asset_url to an s3:// URL. Browsers can only fetch http(s) URLs.

DeployConfig.asset_url is written to .litestar.json as deployAssetUrl and used by the Vite plugin as the base during vite build. If Litestar serves HTML (template/hybrid/AppHandler transforms), also set PathConfig.asset_url to the same public URL.

from litestar_vite import DeployConfig, ViteConfig, VitePlugin

VitePlugin(
    config=ViteConfig(
        deploy=DeployConfig(
            storage_backend="s3://bucket/assets",
            asset_url="https://cdn.example.com/assets/",
        )
    )
)

For more information about Inertia integration, refer to the Inertia documentation.
